| Rolling range(Model) | M8-M25 | M12-M30 |
| Rolling method | Single or continuous piece of thread rolling | |
| Rolling workpiece diameter range | Φ7.2-Φ24.2mm | Φ11.2-Φ29.2mm |
| Thread pitch range | 0.5-2.5P | 0.5-3.0P |
| The maximum length of the thread | Fixed or thru-feeding | |
| Rotate speed | 350-600r/min | 350-600r/min |
| Roller outer diameter | Φ36-Φ80mm | Φ40-Φ85mm |
| Roller inner diameter(groove) | Φ25.4mm(6x3) | Φ35mm(8×4) |
| Roller thickness | 50mm | 50mm |
| Capacity | 20pcs/min | 20pcs/min |
| Host motor | 3HP 8N 2.2KW | 3HP 8N 2.2KW |
| Hydraulic motor | 2HP(1.5KW) | 2HP(1.5KW) |
| Weight | 580KG | 580KG |
| Mechanical volume | 1180*1000*1500mm | 1180*1000*1500mm |
